Product number:DLRK-16IIBM/C1
power supply:380V 3N~ 50Hz
Anti-shock level:protection level Class I / IPX4
Nominal 1 heating capacity/power consumption:16000W/4600W
Nominal 2 heating capacity/power consumption:12000W/4800W
Nominal 3 heating capacity/power consumption:9900W/4500W
LPV(H):3.25W/W
Nominal cooling capacity/power consumption:12500W/4100W
LPV(C):4.02W/W
Circulating Water Flow:2.15m³/h
Water Side Pressure Loss:30kPa
Maximum power consumption/working current:7000W/13A
Circulating water pipe diameter/pipe connection:DN25/1 Coupling
Noise:≤60dB(A)
Refrigerant charge:R410A/2.8kg
External dimensions:955 x 355 x 1250(mm)
Net weight:104kg
