Hien R290 8-16kW Heat Pump: Monobloc Air to Water Heat Pump

The EcoForce Series R290 DC Inverter Heat Pump - your ultimate solution for year-round comfort and eco-efficiency.

This all-in-one heat pump revolutionizes your space with its heating, cooling, and domestic hot water capabilities, all powered by the eco-friendly R290 refrigerant, which has a Global Warming Potential (GWP) of only 3.

Upgrade to the EcoForce Series R290 DC Inverter Heat Pump and embrace a greener, more efficient future for your comfort needs. Say goodbye to the chill with hot water temperatures reaching up to 75°C.

The machine can operates smoothly even under -20°C ambient temperatures.

Hien Heat Pump Saves Up to 80% on Energy Consumption
Hien heat pump excels in energy-saving and cost-effective aspects with the following advantages:
The GWP value of R290 heat pump is 3, making it an environmentally friendly refrigerant that helps reduce the impact on global warming.
Save up to 80% on energy consumption compared to traditional systems.
SCOP, which stands for Seasonal Coefficient of Performance, is used to evaluate the performance of a heat pump system over an entire heating season.

A higher SCOP value indicates higher efficiency of the heat pump in providing heat throughout the heating season.

Hien heat pump boasts an impressive SCOP of 5.19

indicating that over the entire heating season, the heat pump can produce 5.19 units of heat output for every unit of electricity consumed.

The heat pump machine boasts improved performance and comes at a more favorable price.

The noise level at a distance of 1 meter from the heat pump is as low as 40.5 dB(A).

The nine-layer noise reduction measures include:
new type of eddy current fan blades;
low air resistance grille, designed to better fit air flow dynamics; compressor shock absorber pads for vibration reduction;
simulated technology optimized vortex design for finned heat exchanger;
simulated technology optimized pipeline vibration transmission design;
sound-absorbing cotton and peak cotton for noise absorption and reduction;
variable frequency compressor load adjustment;
DC fan load adjustment;
energy saving mode;

Heat pump with a powerful sterilizing mode-Anti-legionella function

With the ability to reach temperatures as high as 75ºC, this cutting-edge product guarantees the elimination of harmful Legionella bacteria and viruses, ensuring the highest level of water safet.

Stable Running at -20℃ Ambient Temperature

Thanks to the unique Inverter technology, can operate efficiently at -20°C, maintain high COP and reliable stability.

Intelligent control, any weather available, automatic load adjust under different climate and environment to satisfy the

demands of summer cooling, winter heating and hot water throughout the year.

The intelligent controller with RS485 is adopted to realize the linkage control between the heatpump unit and the terminal end,

Multiple heat pumps can be controlled and connected to be welmonitored.

With Wi-Fi APP enables you to operate the units through a smart phone wherever and wheneveryou are.

To deliver the best user experience, EcoForce series is designed with a WIFI DTU module for remote datatransferring

and then you can easily monitor the running status of your heating system.

and analyze usage conditions of individual users through the IoT platform.

Smart APP control

Smart APP control brings a lot of convenience to users.

Temperature adjustment, mode switching, and timersetting can be achieved on your smart phone.

Moreover, you can know power consumption statistics andfault record at anytime and anywhere.
